Double
Stainless steel 1.4301. These single and double universal joints feature a simple design with very small tolerances, high precision and performance. These universal joints can be used at speeds up to max. 800 rpm. The torques of the stainless precision universal joints amount to less than the precsion steel version.
SIZES IN MM
Max. operationg angle 90° - At an operating angle of 90° only manual operation is possible.
ALSO AVAILABLE
- Optional Keyways
- Custom Bore Sizes
- Plastic Universal Joints
*If data table appears to be cutoff please scroll horizontally
| Part # | B-H7 | D | A | E | C | Permissible Max - 100 (Nm) | Permissible Max - 200 (Nm) | Permissible Max - 300 (Nm) | Permissible Max - 400 (Nm) | Permissible Max - 500 (Nm) | Permissible Max - 700 (Nm) | Permissible Max - 800 (Nm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| USS12D | 12 | 22 | 105 | 29 | 25 | 11.3 | 7.7 | 6.5 | 5.9 | 5.4 | 5.0 | 3.4 | 0.20 |
| USS14D | 14 | 25 | 119 | 33 | 29 | 19.4 | 11.3 | 9.2 | 7.7 | 7 | 5.9 | 5.4 | 0.30 |
| USS16D | 16 | 29 | 125 | 35 | 30 | 30.8 | 19.4 | 17.8 | 16.2 | 15.1 | 12.8 | 11.9 | 0.43 |
| USS18D | 18 | 32 | 134 | 39 | 30 | 38.9 | 37.8 | 32.4 | 25.9 | 23.2 | 18.5 | 16.2 | 0.56 |
| USS20D | 20 | 40 | 154 | 46 | 32 | 70 | 54 | 43 | 32 | 27 | 26 | x | 1 |
| USS22D | 22 | 40 | 176 | 46 | 38 | 108 | 76 | 54 | 43 | 38 | 27 | x | 1.16 |
| USS25D | 25 | 50 | 199 | 59 | 44 | 173 | 108 | 76 | 65 | 54 | 43 | x | 2.16 |
| USS30D | 30 | 58 | 244 | 66 | 58 | 194 | 119 | 86 | 70 | 59 | x | x | 3.48 |
